| Team Name | : | Cairo University |
| University | : | Cairo University Racing Team |
| Class | : | Class 1 |
| Car Number | : | 140 |
| Country | : | Egypt |
| Cairo Uni. Racing Team – Formula Student is a group of more than 20 students from Mechanical & Electrical Departments in Cairo University Faculty of Engineering with one goal of best representation Cairo University in the FSAE Competition.
Our strength comes from our ability to build simple and cheap vehicles in a country that doesn’t have an automotive industry. Our main sponsors: |
| Length, width, height, wheelbase |
|
||||
| Track (front/rear)1200mm/1100mm | 1200mm/1200mm | ||||
| Weight of car (no driver) | 179kg | ||||
| Weight distribution including 68kg driver (front/rear) | 92/155 | ||||
| Suspension (front/rear) | Double Wishbones/Direct Actuated both front and rear. | ||||
| Tyres (front/rear) | 18.0X6.0-10-R25B Hoosier /18.0X6.0-10-R25B Hoosier | ||||
| Wheels (front/rear) | Kiezer 8X10, 25.4mm offset / Kiezer 8X10, 25.4mm offset | ||||
| Brakes (front/rear) | Mild Steel, hub mounted, 180 mm dia. Drilled. | ||||
| Chassis construction | AISI1020 One piece tubular spaceframe | ||||
| Engine (Electric motor for alternatively fuelled vehicles) | 2012 KTM 450 EXC | ||||
| Bore/stroke/cylinders/cc (Electric motor spec for alternatively fuelled vehicles) | 95mm 63.4mm 1 449.4cc | ||||
| Fuel type (Type of Energy Storage for alternatively fuelled vehicles) | Gasoline | ||||
| Fuel system (Accumulator Spec for alternatively fuelled vehicles) | 2012 KTM 450 EXC Fuel Injection System Controlled by Megasquirt ECU. An O2 sensor is used to complete the loop of information. | ||||
| Max power/max torque | 39.7 kW @ 8500 rpm 48.5 Nm @6500 RPM | ||||
| Transmission | Single 520 chain | ||||
| Differential | Al.7075 CNC Machined Spool. | ||||
| Final drive | 41/11 |
